ДВУТАВРОВАЯ БАЛКА С УКЛОНОМ ВНУТРЕННИХ ГРАНЕЙ ПОЛОК 6-12%. ГОСТ 8239-89. РОССИЙСКИЙ СТАНДАРТ. РАЗМЕРЫ, СПЕЦИФИКАЦИИ
Таблица отражает параметры стальных двутавровых балок с уклоном внутренних граней полок Российского стандарта ГОСТ (GOST). Спецификации, свойства, размеры. Изготовлено в соответствии со стандартами:
GOST 8239-89 ( ГОСТ 8239-89 )
|
Identification |
Nominal dimensions |
Cross-section |
Nominal weight 1m |
Section properties, Static data |
|||||||||||
| mm | A | Ix | Wx | ix | Sx | Iy | Wy | iy | |||||||
| h | b | s | t | R1 | R2 | cm2 | kg/m | cm4 | cm3 | cm | cm3 | cm4 | cm3 | cm | |
|
№10
|
100 |
55
|
4,5
|
7,2
|
7,0
|
2,5
|
12,0
|
9,46
|
198
|
39,7
|
4,06
|
23,0
|
17,9
|
6,49
|
1,22
|
|
№12
|
120 |
64
|
4,8
|
7,3
|
7,5
|
3,0
|
14,7
|
11,5
|
350
|
58,4
|
4,88
|
33,7
|
27,9
|
8,72
|
1,38
|
|
№14
|
140 |
73
|
4,9
|
7,5
|
8,0
|
3,0
|
17,4
|
13,7
|
572
|
81,7
|
5,73
|
46,8
|
41,9
|
11,50
|
1,55
|
|
№18
|
180 |
90
|
5,1
|
8,1
|
9,0
|
3,5
|
23,4
|
18,4
|
1290
|
143,0
|
7,42
|
81,4
|
82,6
|
18,40
|
1,88
|
|
№20
|
200 |
100
|
5,2
|
8,4
|
9,5
|
4,0
|
26,8
|
21,0
|
1840
|
184,0
|
8,28
|
104,0
|
115,0
|
23,10
|
2,07
|
|
№22
|
220 |
110
|
5,4
|
8,7
|
10,0
|
4,0
|
30,6
|
24,0
|
2550
|
232,0
|
9,13
|
131,0
|
157,0
|
28,60
|
2,27
|
|
№24
|
240 |
115
|
5,6
|
9,5
|
10,5
|
4,0
|
34,8
|
27,3
|
3460
|
289,0
|
9,97
|
163,0
|
198,0
|
34,50
|
2,37
|
|
№27
|
270 |
125
|
6,0
|
9,8
|
11,0
|
4,5
|
40,2
|
31,5
|
5010
|
371,0
|
11,20
|
210,0
|
260,0
|
41,50
|
2,54
|
|
№30
|
300 |
135
|
6,5
|
10,2
|
12,0
|
5,0
|
46,5
|
36,5
|
7080
|
472,0
|
12,30
|
268,0
|
337,0
|
49,90
|
2,69
|
|
№33
|
330 |
140
|
7,0
|
11,2
|
13,0
|
5,0
|
53,8
|
42,2
|
9840
|
597,0
|
13,50
|
339,0
|
419,0
|
59,90
|
2,79
|
|
№36
|
360 |
145
|
7,5
|
12,3
|
14,0
|
6,0
|
61,9
|
48,6
|
13380
|
743,0
|
14,70
|
423,0
|
516,0
|
71,10
|
2,89
|
|
№40
|
400 |
155
|
8,3
|
13
|
15,0
|
6,0
|
72,6
|
57,0
|
19062
|
953,0
|
16,20
|
545,0
|
667,0
|
86,10
|
3,03
|
|
№45
|
450 |
160
|
9,0
|
14,2
|
16,0
|
7,0
|
84,7
|
66,5
|
27696
|
1231,0
|
18,10
|
708,0
|
808,0
|
101,00
|
3,09
|
|
№50
|
500 |
170
|
10,0
|
15,2
|
17,0
|
7,0
|
100,0
|
78,5
|
39727
|
1589,0
|
19,90
|
919,0
|
1043,0
|
123,00
|
3,23
|
|
№55
|
550 |
180
|
11,0
|
16,5
|
18,0
|
7,0
|
118,0
|
92,6
|
55962
|
2035,0
|
21,80
|
1181,0
|
1356,0
|
151,00
|
3,39
|
|
№60
|
600 |
190
|
12,0
|
17,8
|
20,0
|
8,0
|
138,0
|
108,0
|
76806
|
2560,0
|
23,60
|
1491,0
|
1725,0
|
182,00
|
3,54
|
